four shafts/bobbins copper wire active pay off machine

Name: four shaftsbobbins copper wire active pay off machine
Brand: Fuchuan
Price: 8000 USD

Brand Name : Fuchuan

Model Number : FC-630

Certification : CE

Place of Origin : China

MOQ : 1set

Price : USD8000

Payment Terms : T/T

Supply Ability : 50SETS/MONTH

Delivery Time : 45days

Packaging Details : simply packed

Color : sky blue

Fit for bobbin : diameter 630mm

Fit copper wire : 0.15mm-1.04mm

shaft no : 4pcs

type : active type

usage : rewinding wire

Contact Now

Merits: It is constant tension,non-twist wire single bobbin pay off machine.Applied to single wire and multiple drawing wires pay off. Match up with the high speed bunching machine,easy to operate,save more floor area.

1. Model: FC-630

2. Usage: Applied to doubling wire pay off, match up with the high speed bunching machine.

3. Single wire diameter: dia0.08-0.64mm

4. Pay off bobbin: PND630

5. Motor power:1.5KW*2

6. Tension control: Pneumatic tension+counterweight regulate

7. Wire speed: It is feedback the singnal to the inverter to control the rotating speed of motor by displacement sensor.

8. Control type: Synchronize with the main machine

9. Protection: Machine is stopped when wire is broken.

10. Fasten type: Cross-shaft type thread fasten

11. Load type: Hydraumatic lift
